combination in different ACLs. The total number of entries in all ACLs cannot exceed the system
maximum listed in the following table.
Maximum number of ACL entries TABLE 11
System Maximum ACL rules per port
region Maximum ACL entries per
system
FSX 800 and FSX 1600 Layer 2 Switch
FSX 800 and FSX 1600 Layer 3 Switch
1015 8192
FCX Layer 2 or Layer 3 Switch 4093 8192
ICX 6610 3067 8192
ICX 6430 507 8192
ICX 6450 3067 8192
ICX 6650 2045 8192
ICX 7750 2047 8192
You configure ACLs on a global basis, then apply them to the incoming or outgoing traffic on specific
ports. The software applies the entries within an ACL in the order they appear in the ACL configuration.
As soon as a match is found, the software takes the action specified in the ACL entry (permit or deny
the packet) and stops further comparison for that packet.
Numbered and named ACLs
When you configure an ACL, you can refer to the ACL by a numeric ID or by an alphanumeric name.
The commands to configure numbered ACLs are different from the commands for named ACLs.
• Numbered ACL - If you refer to the ACL by a numeric ID, you can use 1 - 99 for a standard ACL or
100 - 199 for an extended ACL.
• Named ACL - If you refer to the ACL by a name, you specify whether the ACL is a standard ACL or
an extended ACL, then specify the name.
You can configure up to 99 standard numbered IP ACLs and 100 extended numbered IP ACLs. You
also can configure up to 99 standard named ACLs and 100 extended named ACLs by number.
Default ACL action
The default action when no ACLs are configured on a device is to permit all traffic. However, once you
configure an ACL and apply it to a port, the default action for that port is to deny all traffic that is not
explicitly permitted on the port:
• If you want to tightly control access, configure ACLs consisting of permit entries for the access you
want to permit. The ACLs implicitly deny all other access.
• If you want to secure access in environments with many users, you might want to configure ACLs
that consist of explicit deny entries, then add an entry to permit all access to the end of each ACL.
The software permits packets that are not denied by the deny entries.
Numbered and named ACLs
