8-5
8. Detailed Data Setting
F8.1E.EPS
Switch operations
Display
Output hold time
during calibration
>
ENT
b
1
0
>
ENT
CAL
>
ENT
CAL
>
ENT
SPAn
Y
>
ENT
21.00
%
>
ENT
OPEn/20.84
>
ENT
20.84
%
>
ENT
ZEro
Y
>
ENT
0.98
%
>
ENT
OPEn/0.89
>
ENT
0.89
%
>
ENT
CALEnd
>
ENT
b
10
>
ENT
Measured-value display
>
Figure 8.1 Definition During Calibration
In a semi-automatic calibration, “during calibration” is the time, starting when a calibra-
tion instruction is executed with an infrared switch or a contact input, to make a series
of calibrations, until the preset output stabilization time elapses.
In an automatic calibration, “during calibration” is the time, starting when automatic
calibration is carried out at the calibration start time, until the preset output stabilization
time elapses.
(4) “Error” appears when Error 1 to Error 4 are being issued
