IM 11M13A01-04E 8-20
8.7.3.2Procedure
Use the parameter code table below to set fuel values.
Table 8.17 Setting Fuel Values
Set item Parameter code Set value Engineering units
Amount of water F20 0 to 5 m 3 /kg (m 3 )
vapor in exhaust gas
Theoretical
F21 1 to 20 m 3 /kg (m 3 )
amount of air
X value
F22 0 to 19.99
Absolute humidity F23 0 to 1 kg/kg
of the atmosphere
T8.17E.EPS
8.7.3.3Default Values
When the analyzer is delivered, or if data are initialized, parameter settings are by
default, as shown in Table 8.18.
Table 8.18 Default Settings of Fuel Values
Item Default setting
Amount of water vapor in exhaust gas 1.00 m3/kg (m3)
Theoretical amount of air 1.00 m3/kg (m3)
X value 1.00
Absolute humidity of the atmosphere 0.1000 kg/kg
T8.18E.ESP
8.7.4 Setting Purging
Purging is to remove condensed water in the calibration gas pipe by supplying a span
calibration gas for a given length of time before warm-up of the detector. This prevents
cell breakage during calibration due to condensed water in the pipe.
Open the solenoid valve for the automatic calibration span gas during purging and after
the purge time has elapsed, close the valve to start warm-up.
Purging is enabled when the cell temperature is 100
Њ C or below upon power up and the
purge time is set in the range of 1 to 60 minutes.
F8.05.EPS
Displayed alternately
Figure 8.5 Display during Purging
8.7.4.1Procedure
Use the parameter-code table below to set the purging time.
The allowable input ranges from 0 to 60 minutes.
Table 8.19 Prameter Code
Set item Parameter code Set range Units
T8.19E.EPS
Purging time F15 0 to 60 minutes
8.7.4.2Default Value
When the analyzer is delivered, or if data are initialized, purging time is set to 0
minutes.
