Page 136

IM 11M13A01-04E
10-18
Inspection-related Items in Group G
Code Item
Tuning Engineering Default
unit
setting
G01 mA-output loop
4 to 20 mA
4 mA
G11 Output contact 1
0: Open
Open
1: Closed
G12 Output contact 2
0: Open
Open
1: Closed
G15 Automatic calibration 0: Off
Off
solenoid valve (zero) 1: On
G16 Automatic calibration 0: Off
Off
solenoid valve (span) 1: On
G21 Input1 contact
0: Open
1: Closed
G22 Input2 contact
0: Open
1: Closed
G30 Reset
T10.6G.EPS
10.5 Handling of the ZO21S Standard Gas Unit
WARNING
Use only non-hazardous area.
The following describe how to flow zero and span gases using the ZO21S Standard Gas
Unit. Operate the ZO21S Standard Gas Unit, for calibrating a system classified as
System 1, according to the procedures that follow.
