7. Startup
T7.6E.EPS
ENT A 01 Display after the password has been entered.
ENT C 01 Set the oxygen concentration at 4 mA. Change the parameter code to C11.
Touch the [ ] key to switch to Group C.
ENT C 0 1 Touch the [>] key to move the position of the digit that is flashing to the right.
ENT C 1 1 Touch the [ ] key to enter the numeric value 1.
ENT 0 00 Touch the [ENT] key to display the current set value (0% O 2 has been set).
ENT 0 0 0 Touch the [>] key to move the position of the digit that is flashing to the right.
ENT 0 1 0 Touch the [ ] key to change the numeric value to 1.
ENT 010 If you touch the [ENT] key, all the digits flash.
ENT 010 Touch the [ENT] key again to stop the flashing.
ENT C 11 Touch the [ENT] key once again, and the display will switch to the parameter code selection
display.
ENT C1 1 Set the oxygen concentration at 20 mA. Touch the [>] key to move the position of the digit
that is flashing to the right.
ENT C1 2 Touch the [ ] key to enter the numeric value 2.
ENT 0 25 Touch the [ENT] key to display the current set value.
ENT 025 Touch the [>] key to move the position of the digit that is flashing to the right.
ENT 02 0 Touch the [ ] key to change the numeric value to 0. The numeric value will change from
5 to 6 ... to 9 and back to 0.
ENT 020 If you touch the [ENT] key, all the digits flash.
ENT 020 Touch the [ENT] key again to stop the flashing.
ENT C 12 Touch the [ENT] key once again to switch to the parameter code selection display.
ENT Basic Touch the [>] key together with the [ENT] key to return to the basic panel display.
panel (This is not required if you proceed to make another setting.)(The displayed numeric
display characters indicate the measurement gas concentration.)
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
Ͼ Ͼ
ϾϾ
ϾϾ
Ͼ
Switch operation Display Description
