IM 11M13A01-04E 2-19
2. Specifications
• Part. no. G7004XF or K9473XG Standard Specifications
Primary Pressure: Max. 1 MPa G
Secondary Pressure: 20 to 500 kPa G
Connection: Rc1/4 or 1/4 NPT(F) with joint adapter
Weight : Approx. 1kg
Joint: Rc 1/4, Material: Zinc Alloy
Joint: 1/4NPT(F) , Material: Zinc Alloy
with adapter
T2.13E.EPS
Part No.
G7004XF
K9473XG
Description
A
22
л 15
2-2.2
+0.5
-0
2- л 6.5
40
2- л 6 screw depth 10
40
л 74
Primary Secondary
88
Max.
210
max.
55
Approx. 122
Secondary
pressure
gauge
Panel (Horizontal
mounting)
Panel (Vertical
mounting)
G7004XF: Rc 1/4
K9473XG: 1/4NPT connector
Horizontal
mounting
Vertical
mounting
Panel cut dimensions View A
Unit : mm
