2.4.4 Pressure Regulator for Gas Cylinder (G7013XF or G7014XF)
This regulator valve is used with the zero gas cylinders.
• Standard Specifications
Primary pressure: Max. 14.8 MPa G
Secondary pressure: 0 to 0.4 MPa G
Connection: Inlet W22 14 threads, right hand screw
Outlet Rc 1/4 or 1/4 NPT(F)
Material: Brass body
´ J
HI
H
O
C A
K
A
T
Regulator handle W22 (Right-
handed screw)
Stop valve
Approx. 174
Approx.1
12
IN HI
H AC
A K
T
´ J
O
Outlet ء
Part No.
G7013XF
G7014XF
ء Outlet
Rc1/4
1/4 NPT female screw
Secondary
pressure gauge
Primary
pressure gauge
Secondary
safety valve
Primary
safety valve
Approx. 82
Approx. 59
Approx. 163
