IM 11M13A01-04E 8-3
8. Detailed Data Setting
8.2.3 Selection of Output Mode
You can select a linear or logarithmic output mode. The former provides linear charac-
teristics between the analog output signal and oxygen concentration.
8.2.4 Default Values
When the analyzer is delivered or data are initialized, the output current settings are by
default as shown in Table 8.3.
Table 8.3 Output Current Default Values
Item Default setting
Min. oxygen concentration 0% O 2
Max. oxygen concentration 25% O 2
Output damping constant 0 (seconds)
Output mode Linear
T8.3E.EPS
CAUTION
• When you select logarithmic mode, the minimum output remains constant at 0.1% O
2
,
and the parameter C11 display remains unchanged.
