<10. General Specifications>
10-2
IM 01C25T02-01E
10.2 Optional Specifications
For items other than those described below, refer to each User’s Manual.
Item Description Code
Data configuration at factory Software damping CC
Software Download Function Based on F OUNDATION fieldbus Specification (FF-883)
Download class: Class1
EE
Advanced diagnostics * 3 Multi-sensing process monitoring
• Impulse line blockage detection * 1
• Heat trace monitoring * 2
DG1
*1: The change of pressure fluctuation is monitored and then detects the impulse line blockage. See TI 01C25A31-01E for detailed
technical information required for using this function.
*2: Not applicable for flange mounted differential pressure transmitters and diaphragm sealed differential pressure transmitters
*3: Applicable for EJX series. This option code must be specified with option code EE.
10.3 Optional Specifications (For Explosion Protected type)
Item Description Code
Factory Mutual (FM)
FM Explosionproof * 1 FF1
FM Intrinsically safe and Nonincendive * 1 FS15
ATEX
ATEX Flameproof * 1 KF22
ATEX Intrinsically safe Ex ia * 1 KS26
ATEX Intrinsically safe Ex ic * 1 KN26
Canadian Standards
Association (CSA)
CSA Explosionproof * 1 CF1
CSA Intrinsically safe * 1 CS15
IECEx Scheme
IECEx Flameproof * 1 SF2
IECEx Intrinsically safe and type n * 1 SS25
Contact Yokogawa representative for the codes indicated as ‘-’.
*1: Applicable for Electrical connection code 2, 4, 7, 9, C and D .
< Factory Setting >
Tag Number (Tag plate) As specified in order
Software Tag (PD_TAG) ‘PT2001’ unless otherwise both Tag Number and Software Tag
specified in order
Node Address ‘0xF5’ unless otherwise specified in order
Operation Functional Class ‘BASIC’ or as specified
Primary value * 1 Output Mode (L_TYPE) ‘Direct’ unless otherwise specified in order
Calibration Range (XD_SCALE)
Lower/Higher Range Value
As specified in order
Calibration Range Unit Selected from mmH 2 O, mmH 2 O(68°F), mmHg, Pa, hPa, kPa,
MPa, mbar, bar, gf/cm 2 , kgf/cm 2 , inH 2 O, inH 2 O(68°F), inHg,
ftH 2 O, ftH 2 O(68°F) or psi. (Only one unit can be specified)
Output Scale (OUT_SCALE)
Lower/Higher Range Value
‘0 to 100%’ unless otherwise specified.
Software Damping * 2 ‘2 seconds’ or as specified in order
Static pressur display range ‘0 to 25 MPa’ for M and H capsule and ‘0 to 16 MPa’ for L
capsule, absolute value. Measuring high pressure side.
*1: Primary means differential pressure in case of differential pressure transmitters and pressure in case of pressure transmitters.
*2: To specify this item, /CC option is required.
