Automation Command and Query Reference Manual - Control Reference
PersistenceLastTrace Bool
Sets/Queries whether the last created trace is shown over the persistence trace.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set the persistence display to show the last trace
' on top of the persistence trace.
app.Display.PersistenceLastTrace = True
Example
PersistenceMonoChrome Bool
Sets/Queries whether the persistence mode is monochrome.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set the persistence mode as color.
app.Display.PersistenceMonoChrome = False
Example
PersistenceSaturation Integer
From 0 to 100 step 1 Range
Sets/Queries the population level, relative to the maximum possible level, at which the persistence
traces reach maximum intensity, and above which there are no further changes in color or intensity.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set the persistence saturation level to 60%.
app.Display.PersistenceSaturation = 60
Example
PersistenceStyle Enum
Sets/Queries the type of persistence trace displayed.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set the persistence style to color graded.
app.Display.PersistenceStyle = "ColorGraded"
Example
Values
3d
Analog
ColorGraded
1-88
918500 RevA
