Automation Command and Query Reference Manual - Control Reference
VariableHorZoom Bool
Sets/Queries the ability to zoom horizontally by a continuously variable factor. Note that if a horizontal
zoom of 0.9 is set, while variable zoom is off, the horizontal zoom will be set to 1.0. If the variable
zoom is then enabled, the factor of 0.9 will have been remembered, and it will be used. Note that the
previous value will not be remembered during a power-cycle.
Description
VariableVerZoom Bool
Sets/Queries the ability to zoom vertically by a continuously variable factor. Note that if a vertical
zoom of 0.9 is set, while variable zoom is off, the vertical zoom will be set to 1.0. If the variable zoom
is then enabled, the factor of 0.9 will have been remembered, and it will be used. Note that the
previous value will not be remembered during a power-cycle.
Description
VerPos Double
From -1.5 to 1.5 step (8 digits) Range
Sets/Queries the vertical position of center of the grid on the zoomed trace Fx. The unit of
measurement is the screen height, that is, 0.375 means a shift of three of the eight divisions. A
positive value moves the trace downwards.
Description
VerZoom Double
From 0.1 to 100 step (8 digits) Range
Sets/Queries the vertical magnification of the trace Fx. The magnification will be in a 1 2 5 10
sequence unless VariableVerZoom has been set to True, in which case it will be continuously variable.
Description
XY app.Math.XY
This set of variables controls the display of data in X vs. Y mode. Only Valid when the instrument is in XY, XYSingle,
or XYDual display modes.
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
Example
AxisXRotation Integer
AxisYRotation Integer
ClearSweeps Action
InputX Enum
InputY Enum
Persist3DQuality Enum
Persisted Bool
Persistence3d Bool
PersistenceMonoChrome Bool
PersistenceSaturation Integer
PersistenceTime Enum
ShowLastTrace Bool
1-136
918500 RevA
