Automation Command and Query Reference Manual - Control Reference
TraceTitle String
Any number of characters Range
Sets/Queries the title (prefix) to use when naming saved traces. This prefix will have the family
(sequence) number appended to it when forming the filename.
Description
WaveFormat Enum
Sets/Queries the format to use when saving waveform data into a file. 'Binary' is the most efficient,
storing one or two bytes per data sample, depending upon the number of significant bits. When in
ASCII mode, the Subformat and Delimiter controls define the data format.
Description
Values
ASCII Plain ASCII files with choice of various delimiters
Audio
Binary LeCroy's standard binary waveform format
Excel
MathCad
MATLAB
WaveformDir FileName
Any number of characters Range
Sets/Queries the directory for storing waveform files.
Description
SDA app.SDA
Controls used for SDA (Serial Data Analysis) models only.
AnyHasClientChanged Action
BERParamsOn Bool
BERPow10 Integer
CDRon Bool
ClearSweeps Action
ClkJitterDisplay Enum
ClockModeOn Bool
CompensateForMissingEdges Bool
CompensateNoise Bool
CustomPLL2PoleDamping Double
CustomPLL2PoleDamping2 Double
CustomPLL2PoleNaturalFreq Double
CustomPLL2PoleNaturalFreq2 Double
CustomPLLFilterNumPoles Integer
CustomPLLFilterPoleFreq Double
CustomPLLFilterZeroFreq Double
CustomPLLTransportDelay Double
1-185
918500 RevA
