Automation Command and Query Reference Manual - Control Reference
PatternValue BitPattern
MaxBits=32 NumBits=32 NumBytes=4 AllowedBitValues=01X PaddingChar=X
PadAlign=Right SizeAlign=BitVar Format=Ehex Range
PatternValue2 BitPattern
MaxBits=32 NumBits=32 NumBytes=4 AllowedBitValues=01 PaddingChar=0
PadAlign=Right SizeAlign=BitVar Format=Ehex Range
StartBitInChannel Integer
From 0 to 31 step 1 Range
SupportsDigital Bool
TimeOutLenInNanoSec Double
From 4e-008 to 0.0026214 step 4e-008 Range
ViewingMode Enum
Values
Binary
Hex
WSFrameStart Enum
Values
Falling
Rising
LIN app.Acquisition.Trigger.Serial.Protocol (Standard = " LIN" )
AddressOperator Enum
AddressValue BitPattern
AddressValue2 BitPattern
BitRate Double
DefaultLevel Double
NeedDualLevels Bool
NeededSources Enum
PatternLength Integer
PatternOperator Enum
PatternValue BitPattern
PatternValue2 BitPattern
SupportsDigital Bool
TriggerCondition Enum
ViewingMode Enum
