DigitalPatternArrayLogic8 Enum
Values
DontCare
EitherEdge
FallingEdge
One
RisingEdge
Zero
DigitalPatternArrayLogic9 Enum
Values
DontCare
EitherEdge
FallingEdge
One
RisingEdge
Zero
MSxxDigitalTriggerSet Enum
Allows to select a value for all digital lines of Logic Pattern Trigger. Value can be Zero, One, Don't
Care, Rising Edge, Falling Edge or Either Edge.
Description
Values
Dontcare
EitherEdge
FallingEdge
One
RisingEdge
Zero
MSxxDigitalTriggerType Enum
Logic - permits creation of a simple or complex analog/digital cross-pattern trigger condition with a mix
of 0,1, rising edge, falling edge, either edge, or don't care conditions on up to 5 analog channels and
18/36 digital lines.
Logic Bus - permits creation of a digital trigger that corresponds to a hexadecimal bus value for up to
18/36 digital bits.
Description
Values
Logic
LogicBus
