Automation Command and Query Reference Manual - Control Reference
PersistenceTime Enum
Using SDA.Bits.View, please refer to the corresponding variable in Acquisition.Cx
Description
Values
0.5s
10s
1s
20s
2s
5s
Infinite
ShowLastTrace Bool
Using SDA.Bits.View, please refer to the corresponding variable in Acquisition.Cx
Description
UseGrid String
Any number of characters Range
Using SDA.Bits.View, please refer to the corresponding variable in Acquisition.Cx
Description
View Bool
Using SDA.Bits.View, please refer to the corresponding variable in Acquisition.Cx
Description
ViewLabels Bool
Using SDA.Bits.View, please refer to the corresponding variable in Acquisition.Cx
Description
RESULT app.SDA.Bits.Out.Result
Properties of the type xxxx.Out.Result.yyyy are those of the last completed acquisition. They are not affected if other
cvars are changed after that acquisition was completed. This distinction between "Out.Result" properties and other
cvars is most important when the trigger mode is Single or Stopped. You should treat "Out.Result" properties as read-
only.
EYE app.SDA.Eye
AxisXRotation Integer
AxisYRotation Integer
ClearSweeps Action
LabelsPosition String
LabelsText String
1-210
