Automation Command and Query Reference Manual - Processor Reference
Hysteresis1 Double
From 0 to 10 step 0.1 Range
Hysteresis in divisions around the level on first trace. The signal must enter the hysteresis zone
(shown as a cursor) on one side and exit from the other side to qualify a transition.
Description
Hysteresis2 Double
From 0 to 10 step 0.1 Range
Hysteresis in divisions around the level on second trace. The signal must enter the hysteresis zone
(shown as a cursor) on one side and exit from the other side to qualify a transition.
Description
LevelType1 Enum
Type of level on first trace: absolute/percent and %Pkpk, %0-Min, %0-Max with EMC option
Description
Values
Absolute
Percent
PercentGNDMax
PercentGNDMin
PercentPkPk
LevelType2 Enum
Type of level on second trace: absolute/percent and %Pkpk, %0-Min, %0-Max with EMC option.
Description
Values
Absolute
Percent
PercentGNDMax
PercentGNDMin
PercentPkPk
PercentLevel1 Double
From 0 to 100 step 1 Range
Level on first trace in percent.
Description
PercentLevel2 Double
From 0 to 100 step 1 Range
Level on second trace in percent.
Description
2-62
918500 RevA
