MaskFailX Double
From 0 to 1 step 0.01 Range
Shows the relative horizontal position of the selected mask failure cursors. For example, the user
clicks on a mask failure cursors in the middle of the display. MaskFailX shows the selected horizontal
position that would be 0.5.
Description
MaskFailXEye2 Double
From 0 to 1 step 0.01 Range
MaskFailY Double
From 0 to 1 step 0.01 Range
Shows the relative vertical position of the selected mask failure cursors. For example, the user clicks
on a mask failure cursors in the middle of the display. MaskFailY shows the selected vertical position
that would be 0.5.
Description
MaskFailYEye2 Double
From 0 to 1 step 0.01 Range
MaxFailures Integer
From 1 to 10000 step 1 Range
Set the number of failed bits to display in FailedList.
Description
MeasurementMode Enum
Display a set of parameters measuring various properties of the eye diagram.
Description
Values
Amplitude
Eye
MaskTest
Off
Timing
MonochromeEye Enum
Values
Colorgraded
Monochrome
PercentLevel Integer
From 0 to 100 step 1 Range
