Automation Command and Query Reference Manual - Control Reference
AxisXRotation Integer
From -90 to 90 step 1 Range
Sets/Queries the state of the X Axis rotation control, used only in 3d persistence modes to control the
apparent viewing position. See the general description above for a discussion of the locked and
unlocked persistence modes.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
Set the rotation about the X-axis to 35 degrees for trace F3.
app.Acquisition.F3.AxisXRotation = 35
Example
AxisYRotation Integer
From -90 to 90 step 1 Range
Sets/Queries the state of the Y Axis rotation control, used only in 3d persistence modes to control the
apparent viewing position. See the general description above for a discussion of the locked and
unlocked persistence modes.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
Set the rotation about the Y-axis to 25 degrees for trace F3.
app.Acquisition.F3.AxisYRotation = 25
Example
ClearSweeps Action
DoResetZoom Action
DoStoreToMemoryTrace Action
Equation String
LabelsPosition String
LabelsText String
MathMode Enum
Operator1 Enum
Persist3DQuality Enum
Persisted Bool
Persistence3d Bool
PersistenceMonoChrome Bool
PersistenceSaturation Integer
PersistenceTime Enum
ShowLastTrace Bool
Source1 Enum
UseGrid String
View Bool
ViewLabels Bool
1-125
918500 RevA
