Automation Command and Query Reference Manual - Processor Reference
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Configure F1 to process C1 using Mathcad
app.Math.F1.View = True
app.Math.F1.Source1 = "C1"
app.Math.F1.MathMode = "OneOperator"
app.Math.F1.Operator1 = "MathcadMath"
Example
Advanced Bool
Enables/Disables/Queries the use of the advanced features. When in advanced mode the names
used for source and output vectors, in addition to names used for source and output headers, may be
modified from their default values.
Description
FindScale Action
Set a suitable vertical scale of the Mathcad output trace on the instrument graticule. Valid only when
Manual scaling is specified.
Description
NewSheet Bool
Enables/Disables/Queries the creation of a new Mathcad worksheet.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set function F1 as Mathcad calculation.
app.Math.F1.Operator1 = "MathcadMath"
' Enable creation of a new Mathcad worksheet.
app.Math.F1.Operator1Setup.NewSheet = True
Example
OutputHeaderVar String
OutputVar String
Reload Action
Scaling Enum
Source1Enable Bool
Source1HeaderVar String
Source1Var String
Source2Enable Bool
Source2HeaderVar String
Source2Var String
Status String
WithHeader Bool
WorksheetFilename FileName
2-23
918500 RevA
