CombinedChannels Enum
Select MS-500 operation mode. In "2Combine", sampling rate is up to 2 GS/s and you can use up to
18 digital input lines. In "NoCombine", sampling rate is up to 1 GS/s and you can use up to 36 digital
input lines.
Description
Values
2Combine
NoCombine
LevelC1 Double
From -0.205 to 0.205 step 0.0005 Range
The threshold level determines how the input signal is interpreted. Input voltages less than the
threshold are converted to '0'. Input voltages greater than the threshold are converted to '1'. In this
case, input is analog Channel 1.
Description
LevelC2 Double
From -0.205 to 0.205 step 0.0005 Range
LevelC3 Double
From -0.205 to 0.205 step 0.0005 Range
LevelC4 Double
From -0.205 to 0.205 step 0.0005 Range
LevelExt Double
From -0.41 to 0.41 step 0.001 Range
LineNames String
Any number of characters Range
List of Digital Line Names
Description
MSxxHysteresis2 Double
MSxxHysteresis3 Double
MSxxLogicFamily0 Enum
MSxxLogicFamily1 Enum
MSxxLogicFamily2 Enum
MSxxLogicFamily3 Enum
MSxxThreshold0 Double
MSxxThreshold1 Double
MSxxThreshold2 Double
MSxxThreshold3 Double
