Automation Command and Query Reference Manual - Control Reference
NeededSources Enum
Values
DataSource
NullFrameInd Enum
Values
One
Zero
PatternLength Integer
From 0 to 12 step 1 Range
PatternOperator Enum
Values
Equal
Greater
GreaterOrEqual
InRange
NotEqual
OutRange
Smaller
SmallerOrEqual
PatternValue BitPattern
MaxBits=96 NumBits=8 NumBytes=1 AllowedBitValues=01X PaddingChar=X
PadAlign=Left SizeAlign=ByteVar Format=Ehex Range
PatternValue2 BitPattern
MaxBits=96 NumBits=8 NumBytes=1 AllowedBitValues=01 PaddingChar=0
PadAlign=Left SizeAlign=ByteVar Format=Ehex Range
PayloadChannel Enum
Values
ChannelA
ChannelB
PayloadPreamble Enum
Values
One
Zero
1-47
918500 RevA
