Automation Command and Query Reference Manual - Control Reference

SignalType

Enum

Sets/Queries the signal type for SDA.

Description

' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")

' Set the instrument into SDA mode.
app.SDA.SDAMode = "MaskTest"
' Set signal type as STM16.
app.SDA.SignalType = "STM16"

Example

Values

1000BaseCX

1000BaseLX

1000BaseSX

Custom

DVI

FC1063

FC133

FC266

FC531

FlexRay10.0Mbitss

FlexRay2.5Mbitss

FlexRay5.0Mbitss

FSB533Mhz

FSB667Mhz

FSB800Mhz

HDMI1.3148.5MHz

HDMI1.325MHz

HDMI1.327MHz

HDMI1.374.25MHz

IEEE1394b

OC1

OC12

OC3

RapidIOLPSerial

RapidIOParallel

STM1Optical

STM4Optical

STS1Eye

STS3

USB2.0

SummaryGrid

Action

1-199
