Automation Command and Query Reference Manual - Processor Reference
Reload Action
Reloads a specified Mathcad worksheet. If the worksheet does exist, the system creates an empty
one with a name of the form "UntitledN", where N is an integer.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set function F1 as Mathcad calculation.
app.Math.F1.Operator1 = "MathcadMath"
' Specifies a Mathcad worksheet name.
app.Math.F1.Operator1Setup.WorksheetFilename = "XStream34.mcd"
' Reload a Mathcad worksheet.
app.Math.F1.Operator1Setup.Reload
Example
Scaling Enum
Sets/Queries the method of vertical scaling of the Mathcad output trace on the instrument graticule.
Description
Values
Automatic
Manual
Source1Enable Bool
Enables/Disables/Queries the transmission of source 1 data from the instrument to Mathcad.
Description
Source1HeaderVar String
Any number of characters Range
Sets/Queries the name in Mathcad of input 1 header variable.
Description
Source1Var String
Any number of characters Range
Sets/Queries the name in Mathcad of input variable 1.
Description
Source2Enable Bool
Enables/Disables/Queries the transmission of source 2 data from the instrument to Mathcad.
Description
Source2HeaderVar String
Any number of characters Range
Sets/Queries the name in Mathcad of input 2 header variable.
Description
2-25
918500 RevA
