Automation Command and Query Reference Manual - Control Reference
AxisXRotation Integer
From -90 to 90 step 1 Range
AxisYRotation Integer
From -90 to 90 step 1 Range
This control is used only when Persisted is true and Persistence3d is true. It controls rotation about
the Y axis of the view being persisted.
Description
BipolarLevel Double
From -100 to 100 step 1e-005 Range
ClearSweeps Action
Clear any accumulated result data. Useful for example to restart an average, or parameter statistics.
Description
LabelsPosition String
Any number of characters Range
Sets / Queries the horizontal position of the label attached to the acquisition trace Cx. The unit of
measurement is the unit of the horizontal scale. The measurement is made from the trigger point.
Note that this control is a string, not a numeric value. This allows multiple labels to be positioned, as
shown in the example below.
Description
AxisXRotation Integer
AxisYRotation Integer
BipolarLevel Double
ClearSweeps Action
LabelsPosition String
LabelsText String
LFCutoff Double
Persist3DQuality Enum
Persisted Bool
Persistence3d Bool
PersistenceMonoChrome Bool
PersistenceSaturation Integer
PersistenceTime Enum
ShowLastTrace Bool
Source Enum
UseGrid String
View Bool
ViewLabels Bool
1-96
918500 RevA
