Teledyne LeCroy WaveRunner Automation Command - Manual (Page 361)

Automation Command and Query Reference Manual - Processor Reference
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Configure F1
app.Math.F1.View = True
app.Math.F1.Source1 = "C1"
app.Math.F1.MathMode = "OneOperator"
app.Math.F1.Operator1 = "Rescale"
app.Math.F1.Operator1Setup.Adder = 2.0
app
Example
Adder Double
From -1e+018 to 1e+018 step (9 digits) Range
Sets/Queries the additive constant A in the rescale function Fx = M.Input + A
Description
CustomUnit Bool
Enables/Disables the application of a custom unit of measurement to the rescale function trace Fx.
Description
Multiplier Double
From -1e+018 to 1e+018 step (9 digits) Range
Sets/Queries the multiplicative constant M in the rescale function Fx = M.Input + A
Description
CustomUnit Bool
Multiplier Double
ROOF
app.Math.Fx.OperatorYSetup (Operator = "Roof")
Most positive or maximum values for an ensemble of sweeps, or "Roof"
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Configure F1 to measure the Roof of the first 1000
' sweeps of C1
app.Math.F1.View = True
app.Math.F1.Source1 = "C1"
app.Math.F1.MathMode = "OneOperator"
app.Math.F1.Operator1 =
Example
ClearSweeps Action
ClearSweeps Action
LimitNumSweeps Bool
Sweeps Integer
2-30
918500 RevA
