Automation Command and Query Reference Manual - Processor Reference
RefLevelType Enum
Sets/Queries the unit of measurement for the test level of the reference trace.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set parameter P1 to phase difference.
app.Measure.P1.ParamEngine = "Phase"
' Set the reference level to be measured in absolute units.
app.Measure.P1.Operator.RefLevelType = "Absolute"
Example
Values
Absolute
Percent
PercentGNDMax
PercentGNDMin
PercentPkPk
RefPercentLevel Double
From 0 to 100 step 1 Range
Sets/Queries the test level for the reference trace in percent.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set parameter P3 to phase difference.
app.Measure.P3.ParamEngine = "Phase"
' Set the reference test level in percent.
app.Measure.P3.Operator.RefPercentLevel = 55
Example
RefSlope Enum
Sets/Queries the polarity of the measured reference transitions.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set parameter P1 to phase difference.
app.Measure.P1.ParamEngine = "Phase"
' Set the reference slope to negative.
app.Measure.P1.Operator.RefSlope = "Neg"
Example
Values
Both
Neg
Pos
2-96
918500 RevA
