Automation Command and Query Reference Manual - Control Reference
MSxxHysteresis0 Double
From 0.5 to 0.5 step 0.02 Range
The minimum high voltage level is user definable by the hysteresis control up to 1.4 V above the
threshold. The maximu low voltage level is user definable by the hysteresis control up to 1.4 V below
the threshold. The minimum hysteresis is 100 mV.
Description
MSxxHysteresis1 Double
From 0.5 to 0.5 step 0.02 Range
MSxxHysteresis2 Double
From 0.5 to 0.5 step 0.02 Range
MSxxHysteresis3 Double
From 0.5 to 0.5 step 0.02 Range
MSxxLogicFamily0 Enum
You can select various Logic Families, or select User Defined and define a custom threshold crossing.
Description
Values
CMOS2.5V
CMOS3.3V
CMOS5V
ECL
LVDS
PECL5V
TTL
UserDefined
MSxxLogicFamily1 Enum
Values
CMOS2.5V
CMOS3.3V
CMOS5V
ECL
LVDS
PECL5V
TTL
UserDefined
