Automation Command and Query Reference Manual - Control Reference
Source1 Enum
Sets/Queries the first source of the first operator in Fx. Note that the two possible sources of
Operator1 are Source1 and Source2, Source3 is the second source to Operator2, with the first source
of Operator2 being the ouput of Operator1.
Note that the list of available sources is dependent upon the instrument model, and it's installed
software options.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Define the first source of math function F1 as C3.
app.Math.F1.Source1 = "C3"
Example
Values
BadBits
BadBits2
Bits
Bits2
C1
C2
C3
C4
Decode1
Decode2
Decode3
Decode4
Digital1
Digital2
Digital3
Digital4
dvdt
E100Dta
E10Dta
EnetDta
ET
Eye
Eye2
F2
F3
F4
FiltData
FiltJit
FiltSlv
FLXEye
Harm
I
1-132
918500 RevA
