Automation Command and Query Reference Manual - Control Reference
CalMode
Enum
Configures Cal Output type in WR and WS series of scopes.
Description
' Follwoing example will set CAL output to 1 KHz, 0.5V square wave.
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set cal output to Square wave
app.Acquisition.AuxOutput.CalMode = "Square"
' Set cal output amplitude to 0.5 V with 1 MOhm impedence
app.Acquisition.AuxOutput.Amplitude = "0.5"
' Set cal output frequency to 1 KHz
app.Acquisition.AuxOutput.Frequency = "1000"
Example
Values
DCLevel
DC Level with 1 Mohm o/p impedence
Off
Off
Square
Square wave
Frequency
DoubleLockstep
From 250 to 1e+006 step 10, locked to 1 2.5 5, fine grain allowed=false, on=false
Range
This control only has effect when the AuxOutput mode is "Square".
Sets/Queries the auxiliary output frequency of the squarewave. Units are Hertz.
Note that WaveMaster models (and derivatives) have a limit of 5MHz, WavePro 7000 models (and
derivatives) have a limit of 1MHz.
Description
' Visual Basic Script
Set app = CreateObject("LeCroy.XStreamDSO")
' Set the frequency of the signal from the AUX OUT
' connector to 1 MHz.
app.Acquisition.AuxOutput.Frequency = 1e6
Example
1-11
918500 RevA
