Automation Command and Query Reference Manual - Processor Reference
Protocol2AddressOperator Enum
Values
Equal
Greater
GreaterOrEqual
InRange
NotEqual
OutRange
Smaller
SmallerOrEqual
Protocol2AddressValue BitPattern
MaxBits=32 NumBits=8 NumBytes=1 AllowedBitValues=01X PaddingChar=X
PadAlign=Left SizeAlign=BitFix Format=Ehex Range
Protocol2AddressValue2 BitPattern
MaxBits=32 NumBits=8 NumBytes=1 AllowedBitValues=01 PaddingChar=1
PadAlign=Left SizeAlign=BitFix Format=Ehex Range
Protocol2FilterType Enum
Values
Any
ID
IDData
Protocol2PatternBitLength Integer
From 1 to 128 step 1 Range
Protocol2PatternBitPos Integer
From 0 to 127 step 1 Range
Protocol2PatternOperator Enum
Values
Equal
Greater
GreaterOrEqual
InRange
NotEqual
OutRange
Smaller
SmallerOrEqual
