Section 5: Serial I/O
04/14 60 51216 -- Rev. 6
5.5.6. Configuration
1. Double-click the unit in the list.
─ This displays details about the unit.
2. Select either the Web Configuration or the Telnet Configuration tab:
5.5.7. LEDs / Troubleshooting
The internal Ethernet Interface unit contains the LEDs listed below.
• Power • 10/100 Mb Link • 10/100 Activity
• Diagnostics • Status Chanel 1
•
Simultaneously lit red and green LEDs means something is wrong.
•
f the red LED is lit or blinking, count the number of times the green LED blinks
between its pauses.
The following table explains the LED functions.
LED No. Serial LEDs Meaning
LED 4 Power On or Off
LED 1 10/100 Mb Link steady
green Valid Network connection
LED 2 10/100 Activity blinking Network packets transmitting and receiving
LED 3 Diagnostic steady red and
status blinking green 3 blinks = Network controller error
4 blinks = EEPROM Checksum Error
5 BLINKS = Duplicate IP address on Network
Diagnostic blinking red and
status blinking green 5 blinks = No DHCP response
LED 5 Status steady green Serial port not connected to the Network
Status blinking green Serial port connected to the Network
See LED location on the next page.
