Section 5: Serial I/O
04/14 46 51216 -- Rev. 6
5.4.6. Remote display
The NexWeigh can be connected to a 1600 Series remote display using Port 1.
The NexWeigh should be programmed for Port 1 Output dis, 2400 baud, 7 data bits,
1 stop bits, and nobusy.
NexWeigh TB1 1600 Series TB1
3 TX 3 RX
5 Gnd 2 Gnd
Note: RS232 communications are limited to a length of 50 cable feet.
5.4.7. Computer output
The NexWeigh can be connected to a variety of computer systems utilizing the
continuous or polled outputs. Connections to computers are done using the wiring
chart provided earlier in this section. Ensure that all protocol (baud rate, parity, etc)
matches at both devices connected.
Up to 6 data items are available for transmission; Gross, Tare, Net, Time, Date, and
ID in that order. Each item is separated by a carriage return (CR) and a line feed
(LF). All items enabled in the setup menu will be sent. If the instrument is in Gross
mode, only gross weight will be sent. If the instrument is in Net mode, gross, tare
and net will be sent if GTN is selected in config menu, or net only if NET is selected.
The table below shows a typical wiring diagram to a computer equipped with a db9
connector.
NexWeigh TB1 Computer
2 RX 3 TX
3 TX 2 RX
5 Gnd 5 Gnd
