81
Cursor Measurement
The cursor measurement has three modes: Manual, Track, and Auto
Measure.
Manual Mode
Table 33 - Manual Cursor Function Menu
Option Setting Description
Cursor
Mode
Manual Manually adjust cursors for
measurement.
Type Voltage
Time
Use cursor to measure voltage
parameters.
Use cursor to measure time
parameters.
Source CH1
CH2
*CH3
*CH4
MATH/FFT
REFA
REFB
*REFC
*REFD
Select input signal channel.
Cur A Select this option, turn the
“Universal” knob to adjust
cursor A.
Cur B Select this option, turn the
“Universal” knob to adjust
cursor B.
*Available for 4CH models only.
In this mode, the screen displays two horizontal parallel cursors or vertical
parallel cursors to measure voltage or time. You can move the cursor by
turning the “Universal” knob. Before using cursors, you should make sure
that you have set the signal source as the channel for measuring.
