148
Slope Trigger (>, <, =) Positive slope, (>, <, =) Negative slope
Time: 20 ns - 10 s
Alternate
Trigger
CH1 trigger type: Edge, Pulse, Video, Slope
CH2 trigger type: Edge, Pulse, Video, Slope
CH3 trigger type: Edge, Pulse, Video, Slope
CH4 trigger type: Edge, Pulse, Video, Slope
Display System
Display Mode Color TFT 7.0 in(177.8 mm) diagonal Liquid
Crystal Display
Resolution 480 horizontal by 234 vertical Pixels
Display Color 64K color
Display
Contrast
(Typical state)
150:1
Backlight
Intensity
(Typical state)
300 nit
Wave display
range
8 x 18 div
Wave Display
Mode
Dots, Vector
Persist Off, 1 sec, 2 sec, 5 sec, Infinite
Menu Display 2 sec, 5 sec, 10 sec, 20 sec, Infinite
Screen-Saver Off, 1 min, 2 min, 5 min, 10 min, 15 min, 30 min,
1 hour, 2 hour, 5 hour
Waveform
interpolation
Sin(x)/x, Linear
Color model Normal , Invert
Language English, Arabic, French, German, Russian, Spanish,
Portuguese, Japanese, Korean, Italian, Simplified Chinese,
Traditional Chinese
X-Y Mode
X-pole Input /
Y-Pole Input
(CH1) / (CH2) or (CH3) / (CH4)
Phase Error ± 3 degrees
