Table 22 - Set Trigger Mode to Edge Trigger Function Menu 1
Option Setting Description
Type Alternate The trigger signal comes from two vertical
channels when you use alternative trigger. In
this mode, you can observe two irrelative
signals at the same time.
Channels CHX-CHY
Select any two channels from CH1, CH2,
*CH3, or *CH4 as the sources for alternating
trigger.
Source CH1, CH2,
*CH3,
*CH4
Selects the source channel.
Mode Edge
Set trigger type of the vertical channel signal
to Edge.
Next Page Page 1/2
Go to the second page of the TRIGGER
Menu.
*Available for 4CH models only.
Option Setting Description
Slope
Triggering on rising edge.
Triggering on falling edge.
Triggering on rising edge and falling edge.
Set Up Enter the “Trigger setup menu”
Next Page Page 2/2 Go back to the first page of the TRIGGER
menu.
