64
Table 23 - Set Trigger Mode to Pulse Trigger Function Menu 1
Option Setting Description
Type
Alternate
The trigger signal comes from two
vertical channels when you use
alternative trigger. In this mode,
you can observe two irrelative
signals at the same time.
Channels CHX-CHY Select any two channels from CH1,
CH2, *CH3, or *CH4 as the sources
for alternating trigger.
Source
CH1, CH2,
*CH3, *CH4
Selects the source channel.
Mode Pulse
Set trigger type of the vertical
channel signal (selected by Source)
to Pulse trigger.
Next Page Page 1/2
Enter the second page of
Alternative trigger menu.
*Available for 4CH models only.
Table 24 - Set Trigger Mode to Pulse Trigger Function Menu 2
Option Setting Description
When
Select how to compare the trigger
pulse relative to the value selected
in the Set Pulse Width option.
Set Width 20.0 ns~10.0 s Selecting this option can turn the
universal to set up the pulse width.
Set up Enter the “Trigger Setup Menu”
Next Page Page 2/2 Press this button to return to the
first page.
