126
Record
This mode allows for gap-free recording of waveform data and can be
enabled in SCAN MODE only (refer to “Horizontal Control Knob
section”). It is similar to the above described waveform recorder mode,
however the recorded data can only be played back on-screen, but cannot
be retrieved. Maximum recordable data depends on the timebase in scan
mode. Recorded data can also be stored into external USB flash drive.
Table 62 - Waveform Recording Function Menu
Options
Description
Record Record the waveform persistently
Replay Replay recorded waveform
Option Set the recorder properly
Return Quit the recording function
Figure 79 - Record Screen
Options Setting
Description
Start Start the recording.
Replay Replay the recorded waveform
Copy/Filename When Store Mode is set to USB
key, this will show the filename
