65
Table 25 - Set Trigger Mode to Video Trigger Function Menu 1
*Available for 4CH models only.
Table 26 - Set Trigger Mode to Video Trigger Function Menu 2
Option Setting Description
Polarity
(Normal
)
(Inverted)
Normal triggers on the negative edge of
the sync pulse.
Inverted triggers on the positive edge of
the sync pulse.
Sync All lines
Line Num
Odd field
Even Field
Select appropriate video sync.
Option Setting Description
Type Alternate The trigger signal comes from two
vertical channels when you use
alternatee trigger. In this mode, you can
observe two unrelated signals at the
same time.
Channels CHX-CHY Select any two channels from CH1,
CH2, *CH3, or *CH4 as the sources for
alternating trigger.
Source
CH1, CH2,
*CH3, *CH4
Selects the source channel.
Mode Video
Set trigger type of the vertical channel
signal to Video trigger.
Next Page Page 1/2
Enter the second page of Alternate
trigger menu.
