Video Trigger
Trigger on fields or lines of standard video signals.
Table 18 - Functional Menu of Video Trigger 1
*Available for 4CH models only.
Option Setting Description
Type Video Select the video type trigger. Set the
coupling to AC to trigger the
NTSC, PAL and SECAM video
signal.
Source CH1
CH2
*CH3
*CH4
Select the input source to be the
trigger signal.
EXT
EXT/5
Ext and Ext/5 use the signal applied
to the EXT TRIG connector as the
source.
Polarity
(Normal
) Normal triggers on the negative
edge of the sync pulse.
(Inverted)
Inverted triggers on the positive
edge of the sync pulse.
Sync All lines
Line Num
Odd field
Even Field
Select appropriate video sync.
Next Page Page 1/2 Enter the second page of
“Video trigger menu”.
