117
WARNING: Do NOT turn off the power while the oscilloscope is
updating. Otherwise, the firmware will be corrupted, and the
instrument may not be able to reboot again.
Pass/Fail
The Pass/Fail function can monitor changes of signals and output pass or
fail signals by monitoring the input signal and checking if it is within the
predefined mask or not.
Table 55 - Pass/Fail Function Menu 1
Option Setting Description
Enable On
Off
Turn on Pass/Fail function.
Turn off Pass/Fail function.
Source CH1
CH2
CH3
CH4
Select signal input channel.
Operate Press to run the Pass/Fail test.
Press to stop the Pass/Fail test.
Msg Display
On
Off
Turn on display information of the
waveform pass/fail times.
Turn off display information of the
waveform pass/fail times.
Next Page Page 1/2 Press this button to enter the
second page of Pass/Fail menu.
