75
Set up Sampling mode
Press the “Mode” option button to select “Real Time” or “Equ Time”.
Set up Sampling rate
Adjust the sampling rate by pressing the “Sa Rate” option button and
turning the Time/div front panel knob. The sampling rate is shown at the
corresponding timebase scale.
Display System
The display function can be setup by pressing the “DISPLAY” button.
Table 30- Display System Function Menu 1
Option Setting Description
Type Vectors
Dots
Vectors: Fills the space
between adjacent sample
points in the display.
Dots: There is no link
between adjacent sample
points.
Persist Off
1 sec
2 sec
5 sec
Infinite
Sets the length of time
each displayed sample
point remains displayed.
Intensity Set waveforms’
intensity.
Brightness Set grid brightness.
Next Page Page 1/3 Press this button to
enter second page.
