Page 9

746-257-B5-001, Rev. A1 (11/2013)

Fig. 1-4, Side View, AlphaNet IDH4 Series

RF Connector

1.0 Introduction, continued

Intelligent CableUPS Interface

(located on other side of the board)

Ethernet Port for Local Diagnostics

Tamper Connector

Environmental IO Connector

(IDH4X and IDH4L only)

Battery Monitoring Connection A/B

(IDH4 and IDH4X only)

COM Port (IDH4X only)

Battery Monitoring Connection C/D

(IDH4X only)
