Page 76

76
746-257-B5-001, Rev. A1 (11/2013)
10.1 Definitions and Settings
The following tables display commonly-configured Alpha MIB parameters and provide specific information
with regard to functionality, options, OIDs, types and variables.
Parameter
OID
Description
Access
Type
Value
atiMgntSnmp
1.3.6.1.4.1.926.1.3.1
Object
Identifier
SNMP TRAP ADDRESSES
atiMgmtSnmpTrapTable
1.3.6.1.4.1.926.1.3.1.1
Object
Identifiers
atiMgmtSnmpTrapAddress.1
1.3.6.1.4.1.926.1.3.1.1.1.2.1
SNMP Trap Address (1)
Read/Write
IP Address
0.0.0.0 (default)
atiMgmtSnmpTrapAddress.2
1.3.6.1.4.1.926.1.3.1.1.1.2.2
SNMP Trap Address (2)
Read/Write
IP Address
0.0.0.0
atiMgmtSnmpTrapAddress.3
1.3.6.1.4.1.926.1.3.1.1.1.2.3
SNMP Trap Address (3)
Read/Write
IP Address
0.0.0.0
atiMgmtSnmpTrapAddress.4
1.3.6.1.4.1.926.1.3.1.1.1.2.4
SNMP Trap Address (4)
Read/Write
IP Address
0.0.0.0
SECURE SNMP ACCESS ADDRESS
atiMgmtSnmpAccessTable
1.3.6.1.4.1.926.1.3.1.2
Object
Identifiers
atiMgmtSnmpAccessAddress.1
1.3.6.1.4.1.926.1.3.1.2.1.2.1
Secure IP Address (1)
Read/Write
IP Address
0.0.0.0 (default)
atiMgmtSnmpAccessAddress.2
1.3.6.1.4.1.926.1.3.1.2.1.2.2
Secure IP Address (2)
Read/Write
IP Address
0.0.0.0
atiMgmtSnmpAccessAddress.3
1.3.6.1.4.1.926.1.3.1.2.1.2.3
Secure IP Address (3)
Read/Write
IP Address
0.0.0.0
atiMgmtSnmpAccessAddress.4
1.3.6.1.4.1.926.1.3.1.2.1.2.4
Secure IP Address (4)
Read/Write
IP Address
0.0.0.0
SNMP ACCESS ENABLE
atiMgntSnmpAccess
1.3.6.1.4.1.926.1.3.1.3.0
Object
Identifiers
atiMgmtSnmpSnmpv1Access
1.3.6.1.4.1.926.1.3.1.3.1.0
SNMPv1 Access to Power
Supply Data
Read/Write
Integer
1 = Disable
2 = Enable (Default)
atiMgmtSnmpSnmpv2Access
1.3.6.1.4.1.926.1.3.1.3.2.0
SNMPv2c Access to Power
Supply Data
Read/Write
Integer
1 = Disable
2 = Enable (Default)
CPE & SECURITY KEY (Dual IP)
atiMgmtSnmpAlphaSetAccess
1.3.6.1.4.1.926.1.3.1.3.3.0
"Set to Data Access Key
CIBSET (default)"
Read/Write
Octet String
Set to match the value
of the Data Access Key
atiMgmtSnmpAlphaSetKey)
atiMgmtSnmpAlphaSetKey
1.3.6.1.4.1.926.1.3.1.3.4.0
Data Access Key (Dual IP)
Read/Write
Octet String
CIBSET (default)
atiMgmtSnmpCPESetEnabled
1.3.6.1.4.1.926.1.3.1.3.5.0
Corresponds to whether
or not the action taken on
atiMgmtSnmpAlphaSetKey
was successful. Once
enabled, writing 1(false)
to this variable will disable
CPE sets.
Read/Write
Integer
1=Disabled (False)
2=Enabled (True)
atiMgmtSnmpSnmpCPEAccess
1.3.6.1.4.1.926.1.3.1.3.6.0
Enables the CPE interface -
Dual IP mode
Read/Write
Integer
1=Disabled (Single IP)
2=Enabled (Dual IP)
CPE SETTINGS (Dual IP
)
atiMgmtSysMonitoringCpeStaticMode
1.3.6.1.4.1.926.1.3.2.2.5.2.1.0
Method by which the CPE
acquires its IP address
Read/Write
Integer
1=DHCP
2=Static
atiMgmtSysMonitoringCpeStaticAddress 1.3.6.1.4.1.926.1.3.2.2.5.2.2.0
When the address source is
static, this is the IP address the
CPE will be assigned.
Read/Write
IP Address
0.0.0.0 (default)
atiMgmtSysMonitoringCpeStaticMask
1.3.6.1.4.1.926.1.3.2.2.5.2.3.0
When the address source is
static, this is the mask the
device will use to determine if
other devices are on the local
area network (LAN).
Read/Write
IP Address
0.0.0.0 (default)
atiMgmtSysMonitoringCpeStaticGateway 1.3.6.1.4.1.926.1.3.2.2.5.2.4.0
When the address source is
static, this is the IP address of
the gateway the device will use
for accessing devices not on the
local area network (LAN).
Read/Write
IP Address
0.0.0.0 (default)
10.0 Alpha MIB Parameters
The Alpha MIB Definitions and Settings are subject to change without notice and should only be used
for advanced diagnostics. The SCTE-HMS MIBs listed in
Section 6.0 Data Management should be
implemented for status monitoring & control.
NOTE:
