13.0 Dual IP Mode (Addendum), continued

13.3 Configuring Dual IP Mode, continued

13.3.1 idhdoc04.cfg in Dual IP Mode

In Dual IP mode, the IDH4 Series will first attempt to download the proprietary configuration file

idhdoc04.cfg through the CPE’s interface from a TFTP server on the CPE network. In many

networks, the TFTP server is blocked or disabled, so the IDH4 Series also has provisions to

download this file through the Cable Modem interface from the modem’s provisioning server if

necessary. The filename and TFTP server location may also be specified through special tags in

the DHCP Offer, refer to

Section 13.3.3, Specifying idhdoc04.cfg Download Settings in Dual

IP Mode for details. Similiar to Single IP mode, any IDH4 Series proprietary SNMP MIB setting

may be placed in the modem’s DOCSIS configuration file which would eliminate the need for

idhdoc04.cfg.

Refer

Section 3.2.4, Proprietary Configuration File idhdoc04.cfg for details on using the

idhdoc04.cfg file to propagate custom settings to field-deployed IDH4 Series transponders.

NOTE:

13.3.2 Changing Default idhdoc04.cfg Download Settings in Dual IP Mode

Table 13-3 explains the download options available for the idhdoc04.cfg file in Dual IP mode. The

‘Download Interface’ indicates the network from which the IDH4 series will attempt to download

idhdoc04.cfg, either the CPE network or the more secure cable modem management network.

Parameter

Comments

Value

Search

Order

Download

Interface

atiMgmtSysDownloadConfigAddress

OID 1.3.6.1.4.1.926.1.3.2.1.10.0

Overrides Default Location

0.0.0.0

(Default)

1

CPE

DHCP Server IP

Server or Relay Agent Address

from DHCP lease (No Change

Necessary)

As Set

2

CPE

DHCP Option 54 Server IP

Server or Relay Agent Address

from DHCP lease

As Set

3

CPE

DHCP Tags

See

Section 13.3.3

As Set

4

CPE

docsDevServerConfigTftpAddress

1.3.6.1.2.1.69.1.4.11.0

Automatically set in modem

CM's TFTP

Server Address

5

CM

docsDevSwServerAddress

1.3.6.1.2.1.69.1.3.7.0

Set via DOCSIS configuration file As Set

6

CM

Software Upgrade Server

Set via DOCSIS configuration file As Set

7

CM

Table 13-3, idhdoc04.cfg Download Settings
