4.3

Navigating the Web Page

Once the Web page has been successfully accessed, the operator is able to select a link on the header

bar and the page specific to the topic will open enabling real-time data to be observed.
See Fig. 4-7 for IDH4 Series navigation bar items.

Fig. 4-7, IDH4 Series Site Map

4.0 Web Interface, continued

Commonly used

parameters for

quick diagnostics

of Power Supply,

Communications,

Batteries and

Generator.

AlphaNet

TM

DOCSIS Status Monitor

General Configuration

General

HMS Alarms Advanced Settings

Print

General

Advanced Configuration

APPS

History

Language

Print

Communications: Comprehensive

communications diagnostic parameters
Power Supply: Comprehensive Power

Supply configuration and configurable

parameters
Generator: Comprehensive Generator

configuration and diagnostic parameters
IO - Environment: Status and configuration

of tamper polarity and external I/O devices
HMS Alarms: Status of SCTE-HMS active

alarms, alarm history and alarm threshold

settings

(Requires AlphaApp card)
Overview: Provides AlphaApp card

version and status, plus Utility power

health information.
Battery Management: Configure

technician ID, battery conductance

measurements, battery model and

battery manufacturing dates for

runtime and battery life calculations.

System Logs (requires AlphaApp card): Log

overview page provides snapshot of first 5 entries

from each of the system logs.
Power Supply Events (requires AlphaApp card):

Records daily power supply system events.
Power Supply Configuration (requires

AlphaApp card): Records power supply system

configuration events, many of which are set during

the initial installation.
Battery Events (requires AlphaApp card):

Records battery conductance measurements and

manufacturing dates.
Cable Modem Log: Web page representation of

the DOCSIS modem event log.

Sends the contents

of the selected

Web page to the

computer’s default

printer.

The Web page content

will be displayed in the

selected language.
