Fig. 3-2, Sample DOCSIS Configuration File
Sets Read-Write community string. Set the IP address, netmask and community string to fit your system.
Sets the IP address of where the SNMP traps will be sent. This is typically set to match the IP address of the Network
Management's System Server.
Sets firmware download parameters.
Specifies the IP Address of the TFTP server used for upgrading firmware.
Sets Code Verification Certificate (CVC) for firmware upgrade security per the DOCSIS specification.
A
SNMP MIB Object (11) [Len=21]:docsDevNmAccessStatus.1/4
SNMP MIB Object (11) [Len=21]:docsDevNmAccesslp.1/10.56.21.0
SNMP MIB Object (11) [Len=21]:docsDevNmAccesslpMask.1/255.255.255.0
SNMP MIB Object (11) [Len=25]:docsDevNmAccessCommunity.1/"RW STRING"
SNMP MIB Object (11) [Len=25]:docsDevNmAccessInterfaces.1/"@"
SNMP MIB Object (11) [Len=21]:docsDevNmAccessControl.1/3
SNMP MIB Object (11) [Len=21]:docsDevNmAccessStatus.2/4
SNMP MIB Object (11) [Len=21]:docsDevNmAccesslp.2/10.20.30.40
SNMP MIB Object (11) [Len=21]:docsDevNmAccesslpMask.2/255.255.255.255
SNMP MIB Object (11) [Len=25]:docsDevNmAccessCommunity.2/"RW Trap string"
SNMP MIB Object (11) [Len=25]:docsDevNmAccessInterfaces.2/"@"
SNMP MIB Object (11) [Len=21]:docsDevNmAccessControl.2/5
Software Upgrade Filename(9) [Len=24]:"ModemFirmwareFile.bin"
SNMP MIB Object (11) [Len=20]:docsDevSwAdminStatus.0/2
Software Upgrade TFTP Server (21) [Len=4]:10.56.48.15
Manufacturer Code Verification Certificate (32) [Len=254]: 30 82 03 1A 30 82...
Manufacturer Code Verification Certificate (32) [Len=254]: 04 0A 13 11 41 4D...
Manufacturer Code Verification Certificate (32) [Len=254]: 04 0C 30 0A 06 01...
Manufacturer Code Verification Certificate (32) [Len=36]: 11 A3 41 A6 A7 D9....
B
C
D
E
A
B
C
D
E
Legend
:
3.0 Network Configuration, continued
3.2
The DOCSIS Configuration File, continued
3.2.3 Sample DOCSIS Configuration File Entries
DOCSIS configuration files vary from system to system. Take into consideration your company's policies,
and test the file on a local system prior to widescale deployment.
NOTE:
