IDH4X

IDH4

IDH4L

Power Supply Monitored Parameters

Major Alarm

Aggregate alarm consisting of: Test fail, battery fail, line isolation alarm, output overload, inverter,

over-temperature

Minor Alarm

Aggregate alarm consisting of: Temperature probe error, AC line loss

Input Voltage

Reported from power supply V(in) measurement

Output Voltage

Reported from power supply V(out) measurement

Output Current

0 to 25A standard on port 1

Port 2 requires power suppy DOC option

Output Power

Calculated, reported in AC Watts

UPS Status

AC Line, Standby, Test in progress, Test alarm

Enclosure Door

Open or Closed

Battery Voltage

Individual battery voltage, up to

four strings of 3 or 4 batteries

(maximum 16 batteries),

±100mV per battery.

Individual battery voltage,

up to two strings of 3 or

4 batteries (maximum 8

batteries), ±100mV per

battery.

Individual battery voltage, up to

four strings of 3 or 4 batteries

(maximum 16 batteries),

±100mV per battery. (with SAG option)

Battery Temperature

Reported from power supply battery Remote Temperature Sensor (RTS)

Remote Test Control

Start/Stop power supply test cycle

Generator Monitored Parameters (IDH4X Only)

Status

Generator Off, Running, Alarm

Generator Alarm

Aggregate alarm consisting of: Low oil pressure, engine over-temp, engine over-speed, crank limit,

over voltage, low fuel, water intrusion, pad shear, gas hazard, test fail

Gas Hazard

OK, Alarm

Water Intrusion

OK, Alarm

Pad Shear

OK, Alarm

Enclosure Door

Open, Alarm

Ignition Battery Voltage

±100mV

Enclosure Temperature

±2°C

Low Fuel

OK, Alarm

Remote Test Control

Start / Stop generator test cycle

Cable Modem

Compliance

DOCSIS 1.1 and 2.0

Transmit Frequency Range

5 to 42 MHz

Receive Center Frequency Range

91 to 857 MHz

Output Power Range

TDMA:

+8 to +54 dBmV (32QAM, 64QAM)

+8 to +55 dBmV (8QAM, 16QAM)

+8 to +58 dBmV (QPSK)

S-CDMA:

+8 to +53 dBmV (All modulations of S-CDMA)

Input Signal Range

-15 to +15 dBmV

Channel Bandwidth

6 MHz

Additional Equipment

874-842-21 XP-BSC-3-6

Wire Kit, Battery Sense, 1x36V, 6'

874-842-20 XP-BSC-6-6

Wire Kit, Battery Sense, 2x36V, 6'

874-841-21 XP-BSC-4-6

Wire Kit, Battery Sense, 1x48V, 6'

Surge Protector

(Alpha p/n 162-028-10)

Female/Female connector configuration, “F” type connector with integral ground block. Required for

all installations

11.0 Specifications, continued
