10.1 Definitions and Settings, continued

Parameter

OID

Description

Access

Type

Value

ENVIRONMENTAL MANAGER

atiMgmtSysTempMgr

1.3.6.1.4.1.926.1.3.2.4.0

Object Identifier

atiMgmtSysTempCtrl

1.3.6.1.4.1.926.1.3.2.4.1.0

Environmental Control

Read/Write

Integer

1=off (default)

2=OnTimer

3=OnTemp

4=onTimerTemp

5=on

atiMgmtSysTempStatus

1.3.6.1.4.1.926.1.3.2.4.2.0

Environmental Control Feedback State

Read Only

Integer

1=Contact Open (default)

2=Contact Closed

atiMgmtSysTempMode

1.3.6.1.4.1.926.1.3.2.4.3.0

Environmental Mode (Heat/Cool)

Read/Write

Integer

1=Heater (default)

2=Cooler

atiMgmtSysTempActiveState

1.3.6.1.4.1.926.1.3.2.4.4.0

Environmental Control Contact State

(Open/Closed)

Read/Write

Integer

1=Closed (default)

2=Open

atiMgmtSysTempTemperature

1.3.6.1.4.1.926.1.3.2.4.5.0

Environment Temperature

Read/Write

Integer

1...70ºC

atiMgmtSysTempHysteresis

1.3.6.1.4.1.926.1.3.2.4.6.0

Environmental Temperature Hysteresis

Read/Write

Integer

1...10ºC

atiMgmtSysTempTimer

1.3.6.1.4.1.926.1.3.2.4.7.0

Environmental Default Timer

Read/Write

Integer

0...1440 (30 minute default, 15

minute increments)

atiMgmtSysTempCountdown

1.3.6.1.4.1.926.1.3.2.4.8.0

Environmental Timer Time Remaining

Read Only

Integer

0...1440 (in minutes)

atiMgmtSysTempStatusInvert

1.3.6.1.4.1.926.1.3.2.4.9.0

State Inverted to match the type of

relay operation on the heater mat

controller

Read/Write

Integer

1=No invert (default)

2=Invert

GENERAL CONTROLS

atiMgmtSysTamperPolarity

1.3.6.1.4.1.926.1.3.2.6.1.0

Determines when tamper is active

Read/Write

Integer

1=Alarm On Open (default)

2=Alarm On Close

atiMgmtSysAlphaBusSize

1.3.6.1.4.1.926.1.3.2.6.2.0

Internal microprocessor

communications bus size. Alpha XM3

series power supplies use 9 bit. Alpha

GMX and VMX series supplies use 8 bit

Read/Write

Integer

1=9 Bit (default)

2=8 Bit

atiMgmtSysBatteryCalMode

1.3.6.1.4.1.926.1.3.2.6.3.0

This parameter determines which of the

calibration tables to use in cases where

the battery negative is tied to ground or

when it floats.

Read/Write

Integer

1=Float

2=Negative

atiMgmtSysAlphaBusSpeed

1.3.6.1.4.1.926.1.3.2.6.4.0

Select the speed at which the AlphaBus

will communicate

Read/Write

Integer

1=baud9600

2=baud57600

atiMgmtSysGnrlInfoConfigs

1.3.6.1.4.1.926.1.3.2.7.1

Object Identifier

atiMgmtSysGnrlInfoConfigsMain

1.3.6.1.4.1.926.1.3.2.7.1.1.0 An ASCII string programmed into the

main board non-volatile memory

Read Only

Octet String

Product number, configuration

number serial number, etc.

atiMgmtSysGnrlInfoConfigsDaughter

1.3.6.1.4.1.926.1.3.2.7.1.2.0 An ASCII string programmed into the

C/D battery circuitry (IDH4X only)

Read Only

Octet String

Product number, configuration

number serial number, etc.

atiMgmtSysGnrlInfoConfigsBase

1.3.6.1.4.1.926.1.3.2.7.1.3.0 An ASCII string describing the base

configuration of the device

Read Only

Octet String

i.e. IDH4, IDH4X

ENVIRONMENTAL CONTROL CONNECTOR

atiMgmtSysIO

1.3.6.1.4.1.926.1.3.2.8

Object Identifier

atiMgmtSysIOSelect

1.3.6.1.4.1.926.1.3.2.8.1.0

Designates what function the ENV IO

pins are being used for.

Read/Write

Integer

1=notInstalled(1)

2=lapOnly(2)

3=heaterControlOnly(3)

4=generatorOnly(4)

5=heaterControlAndLap(6)

6=generatorAndLap(6)

96=auxIO_1(96)

97=auxIO_2(97)

98=auxIO_3(98)

99=auxIO_4(99)

atiMgmtSysIOGenState

1.3.6.1.4.1.926.1.3.2.8.3.0

Current state of the generator when

the portable generator sense lines are

being used

Read only

Integer

1=notInstalled

2=genOff

3=genRunning

4=genNotDetected

5=error

10.0 Alpha MIB Parameters, continued
