11.0 Specifications

IDH4X

IDH4

IDH4L

Battery Monitoring

Up to four strings of 36 or 48V

batteries (6V batts configurable up to

two strings)

Up to two strings of 36 or 48V

batteries (6V batts configurable

up to two strings)

Smart AlphaGuard (SAG)

option required for individual

battery monitoring.

Power System Management

Up to five power supplies and an

AlphaGen generator are managed

from a single IDH4X including

coordinated battery charging, system

test and aggregated alarms

N/A

N/A

Management Protocol

Standard ANSI/SCTE-HMS MIBs support basic power supply monitoring. Advanced diagnostics with

battery and power module analytics available via secure SNMP

Advanced Diagnostics

1

Intelligent Power Supply Interface

Power supply user interface displays advanced diagnostics including: DOCSIS modem upstream and

downstream RF levels, IP address assigned by network DHCP server, MAC address and firmware

versions, individual battery voltages to verify correct wire harness installation

Battery State of Health

(requires AlphaApps option)

Power supply internal analytic diagnostics report when batteries should be serviced.

• Battery String Runtime Remaining

• Battery Life Remaining

Utility Status & Events

(requires AlphaApps option)

AC Line Status:

• Utility Performance Status (outages, sags, surges, frequency)

• Utility Events (24-hour and lifetime number of events)

History Log Reports

• Power Supply Event Log (events of daily power supply operation)

• Power Supply Configuration Log (events that occur infrequently)

• Battery Event Log (battery conductance measurements and battery manufactured dates)

Hardware

RF Cable Interface

F-connector, female, 75 Ohm, connector angle better accommodates coax bend radius when installed in

some enclosures

Local Interface

RJ-45, Ethernet, 10/100Mbps

LED Indicators

Alarm/Ready, Upstream registration, Downstream lock, AlphaBus activity, RF level, Ethernet Link, CPE traffic,

Battery Sense harness correctly connected

I/O Control (IDH4X and IDH4LOnly) 6-pin Molex: Digital input, Digital output, 5V, Common

AlphaBus

RJ-11 offset tab: Multiple-power supply and AlphaGen communications

Battery Monitoring

8-pin Molex battery string A/B and

8-pin Molex battery string C/D.

8-pin Molex battery string A/B

10-pin Molex battery string

A/B and C/D (requires SAG

option)

Tamper

NO or NC, software configurable, reads enclosure door magnetic switch

Environment

Operating Temperature

-40 to 65°C / -40 to 149°F

Storage Temperature

-40 to 85°C / -40 to 185°F

Humidity

10 to 90% non-condensing

Regulatory Compliance

FCC Part 15 Class A

EN 50083-2:2006 EMC requirements for CATV equipment

EN 62040-2:2006 Uninterruptable power supply EMC requirements, Category C2

Surge: IEEE 587, Category B3

RoHS: Directive 2002/95/EC

1

Advanced diagnostics are available through Alpha Certified network monitoring systems

Network Communications

DOCSIS (RF) Port Protocols

IPv4, IPv6, UDP, TCP, DHCP, TFTP, SNMPv1,SNMPv2c, HTTP, SNTP

Ethernet Port

Local Mode: HTTP Web interface for local on-site diagnostics

CPE Mode: DOCSIS Cable modem Ethernet CPE functionality

MIBs

Power supply (ANSI/SCTE 38-4)

Other SCTE-HMS MIBs as defined by the SCTE for power supply and generator status monitoring

Alpha proprietary advanced UPS diagnostics
