15

746-257-B5-001, Rev. A1 (11/2013)

MIB Parameter

Object ID

Description

Value

docsDevNmAccessIP

1.3.6.1.2.1.69.1.2.1.2.x

IP address of trap destination, e.g. NMS

server

e.g. 10.20.30.40

docsDevNmAccessIpMask

1.3.6.1.2.1.69.1.2.1.3.x

Must be set to 255.255.255.255 per RFC

4639

255.255.255.255

docsDevNmAccessCommunity 1.3.6.1.2.1.69.1.2.1.4.x

Community string used by NMS to query

transponder

alphanumeric string

docsDevNmAccessControl

1.3.6.1.2.1.69.1.2.1.5.x

Level of SNMP access to IDH4 Series

from IP address specified in

docsDevNmAccessIpMask

4= Read/Only plus Trap

5= Read/Write plus Trap

6= Trap only, no SNMP access

docsDevNmAccessInterfaces

1.3.6.1.2.1.69.1.2.1.6.x

Specifies the set of interfaces from which

requests from this NMS will be accepted

0x40 : Cable interface (typical)

0x80 : Ethernet interface

0xC0 or 0x00 : Both interfaces

docsDevNmAccessStatus

1.3.6.1.2.1.69.1.2.1.7.x

Controls and reflects the status of rows

in this table

4

3.2 The DOCSIS Configuration File, continued

3.2.2 Setting SNMP Trap Destination Addresses

Set the SNMP Trap Destination Addresses via the DOCSIS Configuration File by including the

following SNMP parameters:

Table 3-2, Trap Destination Addresses

3.0 Network Configuration, continued

As an alternative to the docsDevNmAccessTable, SNMP Trap Destination Addresses may be set

through the IDH4 proprietary MIB atiMgmtSnmpTrapTable (OID: 1.3.6.1.4.1.926.1.3.1.1) using

a SNMP MIB Browser or as an entry in the Proprietary Configuration File (see

Section 3.2.4,

Proprietary Configuration File 'idhdoc04.cfg').

NOTE:

Note: "X" denotes the index of the SNMP entry
